EXASTEEL - Bridging Scales for Multiphase Steels

DFG (Deutsche Forschungsgemeinschaft) project BA 2823/8-1 within the SPP (German Priority Program) 1648 "SPPEXA" (Software for Exascale Computing)

Cooperation with:

A. Klawonn (Universität zu Köln),
O. Rheinbach (Technische Universität Bergakademie Freiberg),
J. Schröder (Universität Duisburg-Essen),
G. Wellein (Friedrich-Alexander-Universität Erlangen-Nürnberg)

Abstract:
The project EXASTEEL in the SPP 1648 deals with the computational simulation of advanced high strength steels, incorporating phase transformation phenomena at the microscale using the FE² direct multiscale approach. Thereby in each macroscopic integration point an additional (microscopic) boundary value problem is solved and suitable volume averages of the microscopic responses replace the macroscopic constitutive set of equations compared to classical FEM computations. In a serial set-up this procedure results in high numerical costs especially in the three dimensional case. New, highly efficient, parallel solver algorithms will enable the FE² approach to perform simulations of three dimensional multiscale material science problems. Due to the main objectives of SPPEXA, here the development for the exascale computing on future supercomputers is one of the main aspects.

Construction of Statistically Similar Representative Volume Elements (SSRVEs)

DFG (Deutsche Forschungsgemeinschaft) project no SCHR 570-8/2 (research group 797 "microplast")

Cooperation with:
J. Schröder (Universität Duisburg-Essen),
D. Raabe (Max-Planck Institut für Eisenforschung GmbH)

Abstract:
Micro-heterogeneous high-tech steels enable ambitious engineering constructions. For the design of such random multi-phase microstructures numerical simulation procedures are important for the reliable prediction of the overall response of macroscopic boundary value problems. Direct homogenization schemes, which are designed for such kind of problems, can only be efficient if the complex random microstructure is approximated by significantly less complex representative volume elements (RVEs) capturing the basic morphological attributes of the microscale. This is the main task in the project, where several statistical measures (spectral-density, lineal-path function, Minkowski valuations, etc.) are applied for the construction of statistically similar RVEs (SSRVEs). A main challenge in this period is the design of three-dimensional SSRVEs based on the Electron-Backscatter Diffraction (EBSD) combined with Focused-Ion-Beam (FIB) measurements. The performance of the direct homogenization approach using the constructed SSRVEs is analyzed for representative macroscopic deep-drawing processes.

References:

• D. Balzani, L. Scheunemann, D. Brands, J. Schröder [2014], "Construction of two- and three-dimensional statistically similar RVEs for coupled micro-macro simulations", Computational Mechanics, Volume 54, Issue 5, pp 1269-1284
• J. Schröder, D. Balzani, D. Brands [2011], "Approximation of Random Microstructures by Periodic Statistically Similar Representative Volume Elements based on Lineal-Path Functions", Archive of Applied Mechanics
• D. Balzani, D. Brands, J. Schröder, C. Carstensen [2010], "Sensitivity Analysis of Statistical Measures for the Reconstruction of Microstructures based on the Minimization of Generalized Least-Square Functionals", Technische Mechanik, Vol. 30, pp. 297-315

Simulation of Textile Membranes in Civil Engineering Applications

Cooperation with:
N. Stranghöner (Universität Duisburg-Essen)

Abstract:
The simulation of textile membranes in civil engineering practice is currently based on strong simplifications of the material description. Although the materials show a highly nonlinear stress-strain response in biaxial tension tests, linear elastic models are applied. Furthermore, membrane formulations or approaches based on cord networks are typically used for the numerical calculation of structures which are not capable of reliably predicting e.g. wrinkle formation. In order to improve the current state of the art, in this project new models are developed which describe the material behavior more accurately by taking into account a fully nonlinear continuum mechanical framework.
The models are however constructed such that a practical application may still be enabled.
In addition to that, shell finite element formulations are applied to account for wrinkling.

References:

• D. Balzani, F. Gruttmann, J.Schröder [2008], "Analysis of thin shells using anisotropic polyconvex energy densities", Computer Methods in Applied Mechanics and Engineering, Volume 197, Issues 9–12, Pages 1015–1032
• J. Schröder, D. Balzani, N. Stranghöner, J. Uhlemann, F. Gruttmann, K. Saxe [2011], "Membrane Structures with a Nonlinear Anisotropic Material Behavior – Aspects of Material Testing and Numerical Simulation", Bauingenieur, Volume 9-2011, Pages 381-389

Relaxed Incremental Variational Formulation for Damage at Large Strains with Application to Fiber-Reinforced Materials and Materials with Truss-like Microstructures

Cooperation with:
Daniel Peterseim (Universität Augsburg, Numerische Mathematik)
M. A. Peter (Universität Augsburg, Angewandte Analysis)
M. Ortiz (California Institute of Technology CALTECH, Pasadena, USA)

Abstract:
Our project investigates the formidable challenge of predicting progressive material degradation, particularly in soft biological tissues and engineered systems subjected to mechanical stress. With a specific focus on damage mechanisms within arterial walls—influenced by atherosclerotic plaque development and interventional procedures like angioplasty—we develop computational frameworks designed to capture the complex interplay of stress-softening, hysteresis, and strain-softening phenomena. A fundamental hurdle is the inherent ill-posedness of classical damage models; this arises from the non-convexity of the underlying energy landscapes, leading to undesirable mesh-dependent localization effects.

Traditional strategies for addressing these instabilities rely on regularization techniques, including spatial methods like gradient-enhanced formulations and phase-field models, alongside temporal approaches that incorporate rate-dependent viscosity. However, our project centers on an alternative approach known as relaxation. Here, we replace non-convex energy densities with their corresponding semiconvex envelopes, effectively recovering a well-posed problem. This method elegantly avoids the introduction of artificial length scales or rate dependencies, and instead characterizes damage through homogenized microstructural patterns inherently encoded within oscillating gradients. While analytical relaxation can furnish exact solutions for simplified cases, such as hyperelastic materials, practical applications involving finite-strain damage in complex materials like arteries necessitate robust numerical approximations.

To this end, our contributions encompass hierarchical rank-one convexification techniques and adaptive convexification strategies specifically tailored for microsphere-based models. These techniques are designed to bridge the scales between microscopic cavitation events and macroscopic softening behaviors. Recent advancements leverage optimization-based frameworks, iteratively approximating semiconvex envelopes directly within finite element computations. While these methods hold substantial promise for clinical applications—for example, optimizing stent placement to minimize iatrogenic arterial injury—significant challenges remain in simultaneously achieving computational efficiency and maintaining rigorous physical fidelity, particularly when confronted with inelastic and large-strain scenarios. Ongoing collaborative efforts are directed toward continually refining discretization schemes and rigorously validating our models against experimental datasets, with the ultimate goal of advancing predictive capabilities across both biomedical and industrial applications.

References:

• M. Köhler, T. Neumeier, M. A. Peter, D. Peterseim, and D. Balzani, [2024], “Hierarchical Rank-One Sequence Convexification for the Relaxation of Variational Problems with Microstructures.” Computer Methods in Applied Mechanics and Engineering, DOI: https://doi.org/10.1016/j.cma.2024.117321.
• D. Balzani, M. Köhler, T. Neumeier, M. A. Peter, and D. Peterseim, [2023] “Multidimensional Rank-One Convexification of Incremental Damage Models at Finite Strains.” Computational Mechanics, DOI: https://doi.org/10.1007/s00466-023-02354-3.
• M. Köhler and D. Balzani. [2023] “Evolving Microstructures in Relaxed Continuum Damage Mechanics for the Modeling of Strain Softening.” Journal of the Mechanics and Physics of Solids, DOI: https://doi.org/10.1016/j.jmps.2023.105199.
• M. Köhler, T. Neumeier, J. Melchior, M. A. Peter, D. Peterseim, and D. Balzani, [2022], “Adaptive Convexification of Microsphere-Based Incremental Damage for Stress and Strain Softening at Finite Strains.” Acta Mechanica, DOI: https://doi.org/10.1007/s00707-022-03332-1.
• T. Schmidt and D. Balzani [2016], “Relaxed Incremental Variational Approach for the Modeling of Damage-Induced Stress Hysteresis in Arterial Walls.” Journal of the Mechanical Behavior of Biomedical Materials, DOI: https://doi.org/10.1016/j.jmbbm.2015.08.005.
• D. Balzani and M. Ortiz [2012], "Relaxed incremental variational formulation for damage at large strains with application to fiber-reinforced materials and materials with truss-like microstructures", International Journal for Numerical Methods in Engineering, DOI: 10.1002/nme.4351

Dynamischer Faserauszug

Abstract:
Vorgeschädigte Strukturen aus faserbewehrten Kompositwerkstoffen bewahren bei dynamischer Belastung ihre strukturelle Integrität aufgrund der rissüberbrückenden Wirkung der Bewehrungsfasern. Bei dynamischen Beanspruchungen, welche zu einer Relativverschiebung der Rissufer führen, werden die rissüberbrückenden Fasern gedehnt und gegebenenfalls (weiter) aus der sie umgebenden Matrix gezogen. Gegenstand des Forschungsprojektes ist die Beschreibung dieses dynamischen Faserauszuges. Notwendig ist unter anderem die Modellierung des sukzessiven Ablösens der Faser von der Matrix, welches maßgeblich von der (Zug-)Wellenausbreitung in der Faser beeinflusst wird und umgekehrt Auswirkungen auf die Wellenausbreitung in die umgebende Matrix hat. Die Untersuchungen finden für den Auszug von modernen Faserbewehrungen aus spröden Matrices wie Beton statt.

Referenzen:

• "Analytical and Numerical Modelling of a Sub- and Supersonic Moving Load Front Along a Rod’s Skin", W. E. Weber, Y. F. Fangye, D. Balzani, B. W. Zastrau, Kapitel 26 in "Advanced Methods of Continuum Mechanics for Materials and Structures", Eds.: K. Naumenko and M. Aßmus; 2016, DOI: 10.1007/978-981-10-0959-4_26
• "On the Mechanical Modeling and Analysis of the Dynamical Fiber Pullout Mechanism Taking into Account the Damage and Viscoelasticity of the Bond", Dissertation Aussama Azzam, M.Sc., 2015

Impakt auf Strukturen aus faserverstärktem Beton

Abstrakt:
Impakteinwirkungen führen zu besonders hohen Beanspruchungen in Strukturen aus faserverstärktem Beton. Um sowohl Personen und Tiere als auch Güter zu schützen, müssen die gebauten Strukturen einen hohen Impaktwiderstand aufweisen. In diesem Forschungsprojekt steht die skalenübergreifende Modellierung der Vorgänge im Material aufgrund von Impakteinwirkungen im Vordergrund. Besondere Berücksichtigung finden die Phänomene Wellenausbreitung, Dämpfung und anisotrope Schädigung einschließlich Verbundversagen. Ein weiteres Ziel ist die Bereitstellung geeigneter Representativer Volumenelemente.

Referenzen:

• "Analytical and Numerical Modelling of a Sub- and Supersonic Moving Load Front Along a Rod’s Skin", W. E. Weber, Y. F. Fangye, D. Balzani, B. W. Zastrau, Kapitel 26 in "Advanced Methods of Continuum Mechanics for Materials and Structures", Eds.: K. Naumenko and M. Aßmus; 2016, DOI: 10.1007/978-981-10-0959-4_26
• Balzani, Daniel; Brands, Dominik; Schröder, Jörg. Construction of statistically similar representative volume elements. In: Plasticity and Beyond. Springer Vienna, 2014. S. 355-412.
• "ANALYTICAL DESCRIPTION OF FRC SUBJECTED TO TRANSIENT LOADS“, W. Weber, B. W. Zastrau, erschienen in "Journal of Theoretical and Applied Mechanics", Vol. 51, No. 1, S. 183-194; 2013

Memristives Materialverhalten

Cooperation with:
A. Franze (Institute of Mechanics and Shell Structures, Technical University Dresden)

Abstrakt:
Dieses Projekt behandelt das dynamische Verhalten von Materialien mit memristiven Eigenschaften. Hierbei wird der Begriff der Memristanz aus der Elektrotechnik übernommen. Er bezeichnet das Verhalten des sogenannten Memristors, einem nichtlinearen Widerstand mit Speicherfunktion. Übertragen auf das Gebiet der Mechanik entspricht dies einem Material mit nichtlinearen, geschichtsabhängien Dämpfungseigenschaften. Untersuchungsgegenstand sind effiziente Methoden, mit denen Strukturen mit memristiven Materialeigenschaften berechnet werden können.

Referenzen:
<2 weitere Referenzen sind noch im Druck>

• • Haas, L., Untersuchung elektro-mechanischer Analogien unter besonderer Berücksichtigung von Memristoren (Investigation of electro-mechanical analogies with particular consideration of memristors), Bachelorarbeit. Institut für Mechanik und Flächentragwerke, Technische Universität Dresden, Dresden, 2015

Multiskalige Modellierung, Simulation und Optimierung von Abbauwerkzeugen hinsichtlich ihres Verschleißes

Project C6 within the SFB (Sonderforschungsbereich) 837 „Interaction Modeling in Mechanized Tunneling“

Coorporation with:
K. Hackl (Ruhr-Universität Bochum)

Abstract:
Wear of the mining tools of the mechanized tunneling machines reduces the efficiency of the tunneling process. In order to gain a deeper understanding of the wear process, to predict the life time of the mining tools and from that, to optimize them regarding wear, this project deals with modeling and simulation of the mining tools. Therefore, the two involved wear mechanisms, surface disruption and abrasion, are investigated. For the modeling of the surface disruption on the microscale, the Finite Cell Method (FCM) is combined with the eigenerosion algorithm to simulate ductile crack propagation. This method is applied on Statistically Similar Representative Volume Elements (SSRVE) that are generated computationally based on XRCT scans of the metallic microstructure. The overall material behavior is obtained by homogenization with the mean field method. For investigating the abrasive wear on the macroscale, a damage-plasticity material model is developed. Additionally, the influence of the soil on the wear of the mining tools is obtained by simulating simple scratch tests with the Discrete Element Method (DEM).

Referenzen:

• Wingender, D. & Fritzen, F. & Jänicke, R. (2018), "Reduced order modeling of viscoelastic properties of asphalt concrete", Proceedings in Applied Mechanics. Vol. 18. [DOI]
• Wingender, D. & Balzani, D. (2019), "Simulation of subcritical crack propagation in hard metal microstructures", Proceedings in Applied Mechanics. Vol. 19. [DOI]
• Wingender, D. & Balzani, D. (2020), "Extension of the eigenerosion approach to ductile crack propagation at large strains and its application on hard metal microstructures", Proceedings in Applied Mechanics. Vol. 20. [DOI]
